Two-element measuring instrument is widely used in machinery, electronics, mold, injection molding, hardware, rubber, low voltage electrical appliances, Magnetic materials, precision hardware, precision stamping, connectors, connectors, terminals, mobile phones, household appliances, computers (computers), liquid crystal TV (LCD), printed circuit boards (PCB), automobiles, medical instruments, watches, instruments, screws, springs, gears, cams, threads, radius template, thread template, wire and cable, cutting tools, bearings, stamping parts , screen, test screen, cement screen, mesh (steel mesh, SMT template), etc.
| Model number | 2010 | 3020 | 4030 |
| XYZ measuring stroke | 200*100*200 | 300*200*200 | 400*300*200 |
| Working distance | 90mm | ||
| The overall dimensions | 1280*661*1700 | 1321*800*1700 | 1400*1000*1700 |
| Maximum load | 30Kg | 30Kg | 30Kg |
| Instrument weight | 90Kg | 150Kg | 250Kg |
| Power supply | 220V+10%, 50HZ-60HZ | ||
| Indication error | (3.0+L/200) μm | ||
| Industrial computer | Core Duo 2.8/ Memory 2G/ hard drive 320G/19" LCD color display | ||
| Contact probe | RENISHAW MCP contact probe (optional) | ||
| Control drive count | Taiwan TBI high precision toothless screw | ||
| system | Taiwan TBI high precision V-shaped ball guide rail | ||
| HH-600 multifunctional control box | |||
| 1μm closed glass grating ruler | |||
| Image system | Sony Chip HD Color 1/3" camera + image card | ||
| Image magnification 28 X-800X | |||
| Wu Guang high-definition continuous magnification lens/magnification 0.7-4.5X | |||
| Optional: 0.5X objective lens, magnification 15-115X | |||
| Optional: 2x objective lens, magnification 60-460X | |||
| Light source system | LED Ring Surface Light source + Contour LED cold light source | ||
Product features:
1. All three shafts are driven by Taiwan high-precision V-shaped guide rail and precision toothless screw, with low noise and vibration, and minimal dynamic geometric error and deformation;
2. Adopt high quality granite marble base and column, with good temperature stability and effective deformation resistance.
3. Granite marble workbench, small inertia, to ensure high speed operation of positioning accuracy and steady-state performance.
4. Finite element structure analysis and optimization structure design ensure the whole system of high precision and high stability.
5. KMN integrated control box with British technology is adopted to realize computer synchronous control and adjustment of lighting.
