Air Cooled Xenon Lamp Aging Test Chamber

Xenon lamp test chamber adopts xenon arc lamp that can simulate the full sunlight spectrum to reproduce the destructive light waves in different environments, which can provide corresponding environmental simulation and accelerated test for scientific research, product development and quality control.
Availability:
Quantity:

Details:

Xenon lamp test chamber adopts xenon arc lamp that can simulate the full sunlight spectrum to reproduce the destructive light waves in different environments, which can provide corresponding environmental simulation and accelerated test for scientific research, product development and quality control. Xenon lamp test chambers can be used for the selection of new materials, the improvement of existing materials or the change test to evaluate the durability of material composition changes, and can well simulate the changes caused by material exposure to sunlight under different environmental conditions.


Model number 150 (Air-cooled) 225 (Air-cooled type) 408(Air-cooled type)
Studio size (DxWxH)mm 500x600x500 500x600x750 800x850x650
Overall dimensions (DxWxH)mm 1030x1090x1640 1440x1280x2060 1440x1380x2060
Gross power 11.5 KW 12.5 KW 14.5 KW
Net weight 340KG 460KG 660KG
Blackboard temperature range 63 ℃ ~ 100 ℃
Temperature range 65~98%R.H
Rainfall cycle 1-240 minutes, interval (break) adjustable
Measured wavelength 400nm-1000nm
Xenon lamp power Imported 1.8KW (life 2000 hours)
Duration of rainfall 1-9999 minutes, adjustable
Water spray pressure 0.12 ~ 0.15 mpa
irradiance 150W/m2 736W/m2


air cooled xenon lamp aging test chamberxenon lamp climate aging resistance test chamber


Features:

◆ Full spectrum xenon lamp.

◆ A variety of filter systems to choose from.

◆ Water spray function.

◆ Relative humidity control.

◆ Test chamber air temperature control system.

◆ irregularly shaped flat product rack, easy to place products

◆ Xenon arc lamp imported from the United States.

◆ Easy to install, easy to use, and basically do not require daily maintenance.

◆ The service life of the xenon arc lamp depends on the level of irradiance used, and the life of the general lamp is 1600 hours. The lamp is quickly and easily replaced, and the long-acting filter ensures that the required spectrum is maintained.

◆ The latest air-cooled technology xenon lamp, to solve the problem of high failure rate of water-cooled xenon lamp cooling mode, the user can replace the lamp easily; Easy to maintain.
